Product Description

Product Model		CSSG212
Power requirements		AC 100 ~ 120V/200 ~ 240V, 50/60Hz
Working temperature		-28℃~60℃
Working humidity		20%-95% (Non-condensing)
Working environment		Indoor
Speed of throughput	RFID	Maximum 35/ minute
	Fingerprint	Maximum 30/ minute
Lane width(mm)		600-800
Dimensions(mm)		L=1400, W=140, H=955 （customizable）
Dimension with packing(mm)		L=1500, W=300, H=1100
Net weight(kg)		Single core=90 Dual core=99
Weight with packing(kg)		Single core=109 Dual core=119
Cabinet material		SUS304 Stainless Steel
Barrier material		Acrylic Glass or Tempered Glass (thickness 8mm)
Barrier movement		Swing
Emergency mode		Y
Security level		Medium
MCBF		5 million
Options/Accessories		Counter, Remote Control,Access Control
IR Sensor		6 pairs(Customizable)
Housing Thickness		2.01.5mm(TopHousing)
Rated Power		40W-250W
Input Signal		12vdc/RS485/dry contact

Chisung Intelligence Technology (Shenzhen) Co., Limited | China Guangdong

Features

Reliability

• SUS304 stainless steel case ensures long-lasting durability • High quality electrical components Safety Features.
• All smooth finishing. No exposed screws.
• Ergonomic design makes card and fingerprint authentication fast & simple for users.

Built-in Reader Integration

 • CSSG212 plus series already integrated with customers’ preference for either card or fingerprint access control reader which greatly reduces installation time & expenses.
 • CSSG212 plus series and associated access control readers have passed the factory test before shipment.
 • Chisung provides the plug&play device with the lowest price in the whole industry.
